| Part Number | Power | IF(mA) | VF(V) | CCT | Φ(lm) | Efficacy (lm/w) | CRI-min | Viewing angle | Datasheet |
| A-2835H489WD3VW-2-S1-08L-PCT-HR7 | 0.1W | 30 | 2.7 | 4000K | 12 | 163 | 97 | 120° | |
| A-2835D92VBW-S1-08L-PCT-HR7-ER | 0.2W | 60 | 2.75 | 4000K | 16.5 | 100 | 97 | 120° |  |
| A-2835H466WD3VW-2-S1-08L-PCT-HR7-LU | 0.2W | 60 | 2.8 | 4000K | 24.3 | 145 | 97 | 120° | |
| A-2835D92VBW-S1-08L-PCT-HR7-RC | 0.2W | 60 | 2.75 | 4000K | 24.6 | 148 | 97 | 120° | |
| A-2835D4CBW-3-S1-08L-PCT-HR7-K3 | 0.2W | 60 | 2.75 | 4000K | 25 | 153 | 97 | 120° | |
| A-2835D4WD90VW-2-S1-08L-PCT-HR7 | 0.5W | 150 | 2.8 | 4000K | 63 | 145 | 97 | 120° | |
| A-2835D91VBW-2C-S1-08L-HR7-K3 | 1W | 150mA | 6 | 4000K | 110 | 117 | 97 | 120° | |
| A-2835D4CBW-3C-S1-08L-PCT-HR7-K3 | 1W | 100 | 9 | 4000K | 115 | 130 | 97 | 120° | |
| A-2835D90CBW-3C-S1-08L-PCT-HR7-K3 | 1W | 100 | 9 | 4000K | 121 | 142 | 97 | 120° | |
| A-2835D46CBW-3C-S1-08L-PCT-HR7-K3 | 1W | 100 | 9 | 4000K | 114 | 129 | 97 | 120° | |
