| Part Number | Colour | IF(mA) | VF(V) | XY/WD(nm) | IV(mcd) | Viewing angle | Datasheet |
| PC-3216H343W-N | W | 20 | 3.1 | 0.2745/0.2539 | 1900 | 120° |  |
| PC-3216H203BC-N | B | 10 | 2.9 | 464-474 | 160 | 120° | |
| PC-3216U51GC-N | G | 20 | 3.0 | 517-527 | 1400 | 120° | |
| PC-3216S11GC-N | G | 20 | 2.0 | 568-578 | 70 | 120° | |
| PC-3216S31YC-N | Y | 20 | 2.0 | 586-596 | 290 | 120° | |
| PC-3216S22OC-N | O | 20 | 2.0 | 600-610 | 220 | 120° | |
| PC-3216S39FC-N | R | 20 | 2.0 | 617-627 | 280 | 120° | |
| PCF-3216S39FU70GH203BC-AS | B | 20 | 3.1 | 464-474 | 220 | 120° | |
| G | 20 | 3.0 | 515-525 | 1400 | |||
| R | 20 | 2.0 | 617-627 | 300 |
