| Part Number | Power | IF(mA) | VF(V) | CCT | Φ(lm) | Efficacy (lm/w) | CRI-min | Viewing angle | Datasheet |
| AF-5060H343W-3-S1-TLB-HR3-B1 | 0.2W | 60 | 3 | 4000K | 29 | 161 | 80 | 120° |  |
| AF-5060H415W-3-S1-TLB-HR3-B1 | 0.2W | 60 | 3 | 4000K | 26 | 144 | 80 | 120° | |
•提供多种颜色选择，满足不同场合的需求
•高可靠性，采用优质材料和先进的封装工艺
•应用于灯条、灯带、氛围灯等
•外观尺寸：5.0*5.4*1.6mm
| Part Number | Power | IF(mA) | VF(V) | CCT | Φ(lm) | Efficacy (lm/w) | CRI-min | Viewing angle | Datasheet |
| AF-5060H343W-3-S1-TLB-HR3-B1 | 0.2W | 60 | 3 | 4000K | 29 | 161 | 80 | 120° | |
| AF-5060H415W-3-S1-TLB-HR3-B1 | 0.2W | 60 | 3 | 4000K | 26 | 144 | 80 | 120° | |
