| Part Number | Power | IF(mA) | VF(V) | CCT | Φ(lm) | Efficacy (lm/w) | CRI-min | Viewing angle | Datasheet |
| C3535F77W1LA(Ra1)-FC | 1W | 350 | 3 | 4000K | 165 | 160 | 70 | 120° |  |
| C3535K9W1LA(Ra1)-FC | 1W | 350 | 3 | 4000K | 175 | 175 | 70 | 120° | |
| C3535K9W3MA(Ra1)-FC-F | 3W | 700 | 3 | 4000K | 350 | 167 | 70 | 120° | |
| C3535K9W3MA(Ra2)-FC-F | 3W | 700 | 3 | 4000K | 330 | 157 | 80 | 120° | |
| C3535P15W3HB(Ra1)-FC-LVR2-F | 3W | 700 | 3 | 4000K | 380 | 195 | 70 | 120° | |
| C3535P15W3HB(Ra2)-FC-LVR2-F | 3W | 700 | 3 | 4000K | 345 | 176 | 80 | 120° | |
