| Part Number | Power | IF(mA) | VF(V) | CCT | Φ(lm) | CRI-min | Viewing angle | Datasheet |
| C2017K9W3CB(Ra1)-FC-LVR-CZ | 3W | 1000 | 3 | 4000K | 365 | 70 | 120° |  |
| C2017K19W3CB(RA1)-FC-LVR-CZ | 3W | 1000 | 3 | 5700K | 330 | 70 | 120° | |
Guangzhou Branch
Guangzhou Branch
• High power, high luminous efficiency, universal 1-3W.
• High reliability, high thermal conductivity ceramic substrate design.
• Featuring low thermal resistance, the gold wire-free flip-chip packaging shortens the thermal conduction path, resulting in even lower thermal resistance.
•Applied to headlights, daytime running lights, etc.
• Dimensions:2.0*1.6*0.68mm.
| Part Number | Power | IF(mA) | VF(V) | CCT | Φ(lm) | CRI-min | Viewing angle | Datasheet |
| C2017K9W3CB(Ra1)-FC-LVR-CZ | 3W | 1000 | 3 | 4000K | 365 | 70 | 120° | |
| C2017K19W3CB(RA1)-FC-LVR-CZ | 3W | 1000 | 3 | 5700K | 330 | 70 | 120° | |
